P.A Tech Co.,Ltd
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | P.A Tech |
| Certification: | / |
| Model Number: | KM150 |
| Minimum Order Quantity: | 1Set |
| Price: | Negotiable |
| Packaging Details: | Standard Export Package |
| Delivery Time: | Usually within two weeks |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 20-80 Sets |
| Features: | Low Cost, High Work Efficiency, High Yield, Widely Application, Etc | Keyword: | Clamshell Telescopic Arm, Telescopic Excavator Boom Arm |
|---|---|---|---|
| Model: | KM150 | Max.digging Depth: | 15200mm |
| Reach Max.vertical Digging Draudius: | 11825mm | Min.operating Diadius: | 3980mm |
| Max. Operating Height: | 9475mm | Excavator Capacity: | 15ton |
| Application: | Excavation, Steep Slope Excavation Earthwork, River Embankment, Slope Surface Repair Works... | Warranty: | 1 Year |
| After-sales Service Provided: | Online Support,Video Technical Support,Engineers Available To Service Machinery Overseas | Color: | Customer's Request |
| Condition: | New | Other: | OEM Service |
| Factory Test Report: | Available | ||
| High Light: | 15.2m Clamshell Telescopic Arm,3600kg Clamshell Telescopic Arm,3600kg excavator boom and stick |
||
Teledipper Excavator Arms With Hydraulic Clamshell Bucket Slope Excavation Arm
Description of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
P.A Tech Teledipper Excavator Arms With Hydraulic Clamshell Bucket usually used in the job sites of Municipal Engineering, Capital Construction, Hydraulic Engineering, etc, mainly for the deeply excavate, especially for deep and narrow special construction environment.
Application of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
1- Clamshell telescopic arm can be used for excavation, steep slope excavation earthwork, river embankment, slope surface repair works;
2- Municipal pipe network, buried pipe operation engineering, subway repair and long-distance tunnel excavation also need to use Telescopic excavator Long Reach boom do do the job.
3- Telescopic Excavator Boom Arm is also widely used for ditch dredging, river dredging, hydropower station tail water dredging, deep river silt, gravel clearing, etc.
4- Teledipper excavator arms with hydraulic clamshell bucket are also suitable for special conditions with special requirements for depth, width and height.
Teledipper Excavator Arms With Hydraulic Clamshell Bucket Slope Excavation Arm
Parameters of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
| Technical Specifications of KM Series Clamshell Telescopic Arm | |
| Model | KM150 |
| Max.digging depth | 15200mm |
| Max.digging dradius (reach Max.digging depth) |
4670mm |
| Max.vertical digging dradius | 6430mm |
| Max.digging depth (reach Max.vertical digging draudius) |
11825mm |
| Max.operating diadius | 7950mm |
| Max.hoisting height | 2870mm |
| Min.operating diadius | 3980mm |
| Max. operating height | 9475mm |
| Weight of teloscope boom | 3600kg |
| Excavator capacity | ≥15t |
Teledipper Excavator Arms With Hydraulic Clamshell Bucket Slope Excavation Arm
Workshop of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
Construction Site of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
Teledipper Excavator Arms With Hydraulic Clamshell Bucket Slope Excavation Arm
Features of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
P.A Tech Clamshell telescopic arm is very convenient for small and stereo space construction job sites, it is a kind of quick and convenient tooling suitable for city vertical stereo constructions. Reliable telescopic structure of wire rope which could largely improve the excavator clamshell telescopic long boom arm servicing life. And, P.A Tech excavator attachments strictly follow the safety standard of EU EN791, well satisfy the requirements of dynamic and static stability, this could guarantee the high construction security of P.A Tech Hydraulic Telescopic Arm of Excavator.
Service of Teledipper Excavator Arms With Hydraulic Clamshell Bucket KM150:
1-- Six months warranty of products.
2-- Online consultation and answering.
3-- Free customization.
4-- Delivery within 15 days.
If you have any question or want to know more about our excavator attachments,please feel free to send an inquiry to us!We will do the best to help you!
